Copper Bending Machine
The Copper Bending Machine is a specialized equipment used to process copper tubes into desired shapes and is widely used in industries such as HVAC, automotive, plumbing and electronics.
Features
High-precision bending
Our machines use advanced CNC technology to ensure that the bending accuracy of copper tubes reaches ±0.1 mm. This high precision not only reduces material waste, but also meets high-demand industrial standards, and is particularly suitable for precision instrument manufacturing and the production of high-end electronic equipment.
Strong durability
The main body of our machine is made of high-strength alloy steel. After a special heat treatment process, the hardness reaches HRC 58-62, and the wear resistance and impact resistance are significantly improved. Compared with ordinary steel, the service life is extended by about 30%, and stable performance can be maintained under continuous high-intensity working conditions.
High-efficiency motor
Our products are equipped with high-efficiency servo motors with a stable power output of 2.2 kilowatts and a maximum torque of 15 Nm. This motor not only has low energy consumption, but also maintains low noise when running at high speed, ensuring that it does not heat up for a long time and improving overall work efficiency.
Intelligent control system
The Copper Bending Machine have built-in intelligent control systems that support automatic programming bending at multiple angles and radii. Users only need to enter parameters, and the machine can automatically complete complex bending tasks, which is easy to operate, reduces human errors, and improves production efficiency by about 20%.
Technical Parameters
|
Items |
Model |
|
JPMX-503ESK |
|
|
Nominal force (kn) |
500 |
|
Punching dia. range (mm) |
ф4.3～ф30 |
|
Max. thickness (mm) |
16 |
|
Max. width (mm) |
200 |
|
Max. shearing thickness (mm) |
16 |
|
Max. shearing width (mm) |
200 |
|
Max. horizontal bending width (mm) |
200 |
|
Max. horizontal bendind thickness (mm) |
16 |
|
Max. vertical bending size (mm) |
12×120 |
|
Power (kw) |
3×5.5KW |
|
Bending precision (degree) |
±1° |
|
Repeat bending precision (degree) |
±0.5° |
|
First table size (mm) |
1920×1385 |
|
Second table size (mm) |
985×500 |
|
Outside dimension (mm) |
1950×1560×1390 |
|
Container size (mm) |
2060×1660×1650 |
|
Total weight (kg) |
1700KG |
FAQ
Q: What is a Copper Bending Machine?
A: A Copper Bending Machine is a specialized tool designed for bending copper pipes and wires into precise shapes and angles. It ensures accurate, smooth bends without damaging the material.
Q: What are the main applications of a Copper Bending Machine?
A: Copper Bending Machines are commonly used in industries such as plumbing, HVAC, electrical installations, and automotive. They help shape copper pipes and wires for various systems and components.
Q: What are the key features to look for when selecting a Copper Bending Machine?
A: Key features to consider include adjustable bending angles, bending capacity (pipe diameter and thickness), ease of operation, durability, and the type of control system (manual or automatic).
Q: Can a Copper Bending Machine bend other materials besides copper?
A: Yes, many Copper Bending Machines are versatile and can also bend other materials like aluminum, brass, or steel, depending on the machine's specifications and bending capacity.
Q: How does a Copper Bending Machine work?
A: The machine uses mechanical force to apply pressure to the copper pipe or wire, gradually bending it along a specific radius. Some machines use hydraulic or pneumatic systems for smoother bends and higher precision.
Q: What is the difference between manual and automatic Copper Bending Machines?
A: Manual machines require the operator to apply force and adjust the settings, while automatic machines use programmable controls to set the bending parameters, offering more consistency and ease of use.
Q: What are the advantages of using a Copper Bending Machine in industrial applications?
A: The advantages include increased accuracy, speed, and consistency in bending copper, reduced manual labor, and the ability to handle complex shapes and tight tolerances.
Q: What maintenance does a Copper Bending Machine require?
A: Regular maintenance includes cleaning the machine, checking for wear on the bending dies, lubricating moving parts, and ensuring hydraulic or pneumatic systems are functioning properly.
Q: Can a Copper Bending Machine be used for both small and large-scale production?
A: Yes, Copper Bending Machines can be scaled for both small workshops and large production lines, with some machines offering high-speed operation and others focusing on precision for smaller, custom jobs.
Q: How can I improve the lifespan of my Copper Bending Machine?
A: To extend the lifespan, ensure regular maintenance, proper handling, using the correct materials for bending, and avoiding overloading the machine beyond its rated capacity.
